Compliant with IEEE 802.3db and IEEE 802.3ck

Compliant with QSFP-DD800 MSA

Management interface based on CMIS 5.2

Supported CBD remote upgraded (Both MCU and DSP)

Optical Interface: 106.25 Gbps (PAM4) x 8

Electrical Interface: 106.25 Gbps (PAM4) x 8

Parallel 8 Optical Lanes

Up to 100m over OM4 MMF with FEC

Case operating temperature: 15℃ to +70℃

Single 3.3V power supply

Power consumption: 15W Max.

Dual MPO-12/APC connector

RoHS2.0 compliant
